Product Introduction:

This 10kW twin-cylinder diesel generator is engineered for high performance, powered by a robust twin-cylinder engine. With a 10kW rated output, it is well-suited for a variety of applications—from powering equipment on small-to-medium construction sites to providing emergency backup for commercial shops or multiple households. It delivers stable power with a high load capacity, capable of simultaneously running high-draw appliances such as air conditioners and welding machines.

Featuring optimized combustion technology for precise fuel consumption control and a large-capacity fuel tank, the unit offers extended runtime. Its design balances portability with durability; the corrosion-resistant enclosure is built to withstand harsh outdoor environments, and the unit includes integrated protection against overloads and short circuits. Advanced noise-reduction measures ensure quiet operation without compromising power, making it a practical, safe, and stable solution for efficient power supply.

Product Specifications:

Model: TO14000K

Generator Specifications:

Rated Power: 10kW

Maximum Power: 11kW

Rated Frequency: 50Hz

Rated Voltage: 220V/380V

Generator Type: Open-frame

Operating Altitude: ≤ 1500 meters

Power Factor: 0.8/1.0

Phase: Single-phase/Three-phase

Starting Method: Electric start (fully automatic option available)

Fuel Type: 0# or -10# Diesel

Engine Specifications:

Engine Type: Twin-cylinder, V-type, air-cooled, four-stroke, direct-injection

Engine Model: TO2V88

Displacement: 875ml

Oil Capacity: 2.2L

Runtime: 8–12 hours

Fuel Consumption (at no-load): 205 g/kW·h

Recommended Oil: SAE 10W-30 (or CD grade)

Fuel Tank Capacity: 26L

Rotational Speed: 3000 r/min

Dimensions (L×W×H): 868 × 647 × 716 mm

Net Weight: 220 kg
